| import pandas | |
| import keras | |
| from keras.layers import Dense, Dropout, BatchNormalization | |
| import csv,math | |
| import numpy as np | |
| import matplotlib.pyplot as plt | |
| from sklearn import preprocessing | |
| from sklearn.preprocessing import MinMaxScaler | |
| from sklearn.metrics import mean_squared_error | |
| seed = 420 | |
| np.random.seed(seed) | |
| scaler = MinMaxScaler(feature_range=(0, 1)) #define normalization | |
| #model function | |
| def base_model(): #create model | |
| model = keras.Sequential() | |
| model.add(Dense(256,activation='relu',input_shape=(1,4))) | |
| model.add(Dense(128, activation='relu')) | |
| model.add(Dense(64,activation='relu')) | |
| model.add(Dense(32,activation='relu')) | |
| model.add(Dense(16,activation='relu')) | |
| model.add(Dense(8,activation='relu')) | |
| model.add(Dense(4,activation='relu')) | |
| model.add(Dense(1, activation='sigmoid')) | |
| model.compile(loss='mean_squared_error',optimizer='adam') | |
| return model | |
| #data function | |
| def matrix(): #extract the data from excel, and return, all data, train input, train output, test input, test output | |
| results = [] #excel table | |
| with open('input.csv','rt', encoding="ascii") as csvfile: #load excel file | |
| reader = csv.reader(csvfile, delimiter=',', quotechar='|') | |
| for row in reader: | |
| results.append(row) | |
| table=[] #only necessary data | |
| for row in range(1,len(results)): #load only data thats important | |
| if(results[row][12]!=''): | |
| table.append([results[row][4],results[row][5],results[row][7],results[row][8],results[row][12]]) | |
| table=np.float64(table) #convert to numpy matrix | |
| table=np.delete(table,25,axis=0) #delete one zero value | |
| table = scaler.fit_transform(table) #normalize | |
| train_input,train_output = [],[] | |
| precentage_of_train_data = 0.92 #precentage of all data that will be used for training | |
| for row in range(0,int(len(table)*precentage_of_train_data)): #load train data | |
| train_input.append([table[row][0],table[row][1],table[row][2],table[row][3]]) #input | |
| train_output.append([table[row][4]]) #output | |
| test_input, test_output = [], [] | |
| for row in range(int(len(table)*precentage_of_train_data),len(table)): #load test data | |
| test_input.append([table[row][0],table[row][1],table[row][2],table[row][3]]) #input | |
| test_output.append([table[row][4]]) #output | |
| #convert to other shape | |
| train_input=np.expand_dims(train_input,1) | |
| train_output=np.expand_dims(train_output,1) | |
| test_input=np.expand_dims(test_input,1) | |
| test_output=np.expand_dims(test_output,1) | |
| return table, train_input, train_output, test_input, test_output | |
| model = base_model() | |
| print(model.summary()) | |
| table, tx, ty, dx, dy = matrix() | |
| model.fit(tx, ty, validation_data = (dx,dy), epochs=300, batch_size=12, verbose=2) | |
| #define predictions and true data | |
| test_predict = model.predict(dx.copy()) #predictions for testing data | |
| train_predict = model.predict(tx.copy()) #predictions for training data | |
| #table[:,4] - true results | |
| #format predicted data | |
| table_predicted = table.copy() #create new table for predicted data | |
| for i in range(len(train_predict)): #fill up first rows with train data because thats how we splitted them | |
| table_predicted[i,4]=train_predict[i] | |
| for i in range(len(train_predict),len(table)-1): #and second with test data | |
| table_predicted[i,4]=test_predict[i-len(train_predict)] | |
| #inverse transform normalized data | |
| table = scaler.inverse_transform(table.copy()) | |
| table_predicted = scaler.inverse_transform(table_predicted.copy()) | |
| #calculate root mean squared error | |
| score = math.sqrt(mean_squared_error(table_predicted[:,4],table[:,4])) | |
| print('RMSE:') | |
| print(score) | |
| #graph data | |
| x=np.arange(len(table)).astype(float) #define x axis just for row number of result | |
| plt.scatter(x,table[:,4], label = 'True values') #scatter true results | |
| plt.scatter(x,table_predicted[:,4],alpha=0.6, marker=11, label='Predicted values') #scatter predicted results | |
| plt.axis([0,len(table), #x axis | |
| min([min(table[:,4]),min(table_predicted[:,4])])*1.1, #y axis min | |
| max([max(table[:,4]),max(table_predicted[:,4])])*1.1]) #y axis max | |
| plt.axvline(x=len(train_predict)-0.5,color='r',linestyle='--') #draws line to separate train prediction data and test prediction data | |
| plt.text(len(train_predict), max([max(table[:,4]),max(table_predicted[:,4])])/2, | |
| "Test data", rotation=90, verticalalignment='center') | |
| plt.text(len(train_predict)-2, max([max(table[:,4]),max(table_predicted[:,4])])/2, | |
| "Train data", rotation=90, verticalalignment='center') | |
| #axis and legend | |
| plt.xlabel('Result number') | |
| plt.legend(loc='upper left') | |
| plt.ylabel('Result value') | |
| plt.show() | |
